| TECHNICAL SPECIFICATIONS | |
|---|---|
| Max Flow: | 10 |
| Min Pressure: | 100 |
| Max Pressure: | 2000 |
| Inlet Port Size: | 0.75 |
| Discharge Port Size: | 0.5 |
| RPM: | 1667 |
| Drive Type(s): | Gearbox |
| Material: | Stainless Steel (SS) |
This is a triplex (three plunger rods) positive displacement, reciprocating, plunger pump with gearbox, constructed of a 316 stainless steel manifold, 316 stainless steel valve assemblies, solid ceramic plungers and standard NBR (Buna-N) seals and o-rings. This pump comes complete with a gearbox for easy direct mouning to a gas engine. [See gearbox data sheet 8076-8077-8081)
